Electronic platform scale with printing function

Electronic platform scale is formed by weighing sensor, bearing table and weighing display.

Electronic platform scale with printing function:

Wagon balance scale is divided into mechanical type wagon balance scale and electronic type wagon balance scale according to structure and function. It is widely applied in warehouse, workshop, goods yard and markets.

Structure of electronic wagon balance scale:

Single layer structure full steel scale;

Built-in junction box, beautiful appearance;

High strength scale body and high accuracy;

Surface is under abrasive blasting treatment with strong anti-corrosive property;

Selection of full stainless steel material;

Standard configuration:

High strength whole platform

High precision cantilever beam weighing sensor

Having printing instrument

Intelligent AC/DC application

Full stainless steel anti-surge junction box

1, equipped with sensor performance parameters:
SB type single shear beam type weighing sensor, the main technical indicators are as follows:
Recommended excitation voltage: 6 ~ 15V (DC/AC)
Maximum excitation voltage: 20V (DC/AC)
Rated output: + 2 + 0.1/5mv/V
Nonlinear: + 0.02%F.S
Hysteresis: 0.02%F.S
Repeatability: 0.02%F.S
Creep: + 0.02%F.S/30min
Output impedance: 350 + 1
Safety overload: 125%F.S
Limit overload: 150%F.S
2 with instrument function
A large screen display can be configured to display the weighing data
* configurable printer, which is used to print weighing data and statistical reports.
The weighing management system of computer composition
Different weighing display instrument can have different functions, users can choose according to their actual needs
